Install Satellite Dish Guide

Satellite dish is definitely an equipment used for transmitting data signals towards the signal receiver or receiving data signals from the satellite located in the space. All the satellite dishes look almost similar. You will need to know your latitude and longitude before you start. A great place to fine this post is Multimap simply enter your post code, and the coordinates and displayed below the map. The vertical alignment is the dish angle of elevation and refers back to the angle at which the satellite signals hit the Earth’s surface. In the northern hemisphere, they’re flat - about 15 the further south you go i.e. closer to the equator, the steeper they become. On Sicily they have an elevation angle of 45 and right on the equator of 90.


If you intend to use the satellite dish in Northern France, a standard 53 cm minidish must do just fine but as you move to the southern parts of the country you will have to face rain fade problems, so in order to get good reception during these areas, you will need to increase the dish size to 90 cm while you reach the Spanish border.

You will also wish to measure how long the cable is to make sure that it can get to the dish or antenna from inside your home. You may need to add another cable should you must. You might need a drill and screws for drilling things in position and then securing them.

To prevent any mix-up, each signal must be accurately reflected to separate feed horns so that there is no interruption.

Input your latitude and longitude in your receiver yours will change to mine before adjusting your dish and then tell usals to go to Thor 1W/0.8W. Now go and check again that the mounting pole has always been vertical and not moved underneath the weight of the dish, otherwise this issue needs to be corrected before continuing.

Fix the dish and rotor arm to the motor and adjust the elevation from the dish (declination) according to the motor manual, Or simply adjust it so the face of the dish is all about vertical or tilting up slightly (depending on your Latitude). The azimuth may be the horizontal alignment from the dish while the elevation is the vertical alignment.


Hook up the cables turn turn on to the satellite receiver and television, and tune the television to the input channel for that satellite receiver. If you have used coax cable to connect the satellite receiver towards the TV that will usually be Channel 3. Some satellite receivers put out a tone that changes using the signal strength. I use that with wireless headphones that allow me to hear the tone when I am outside using the dish. Another option is a hand-held signal strength meter like the Satellite Finder. The average home satellite dish is now much smaller (18 to 31 inches) and can easily fit in almost anywhere. They are often mounted on chimneys, under an eave and sometimes on the ground best satellite dish. Work out how much RG-6 coaxial cable you will need to connect the exterior satellite dish to the set-top box receiver in your home. Allow for four to five feet of extra coaxial cable as an error margin.

Then slowly tilt the dish left and right (azimuth movement) to improve the signal strength reading. When you’re satisfied that you have the best signal, using the signal quality bar (not the signal level bar), tighten the azimuth bolts. Then skew (rotational movement) the LNBF to get the strongest signal quality/strength. The primary issue with satellites is that the line of sight cannot be interrupted.

Satellite Installation Guide

Installing a satellite dish system to a home, caravan or motorhome or boat is not as difficult as it may first seem.


Follow the directions that come with your dish on how to properly secure the mount towards the wall. To repair the mounting plate and L-shaped pole, you will need to drill holes for four 10mm plastic wall plugs. Use a spirit level to help keep it straight and mark off your drilling points. 13mm bolts are utilized to hold the mount in position. Once you fit the dish on to the pole and secure it, you can then go on to align (point) it correctly.


satellite dish Set your basic elevation angle. Make reference to the elevation scale on the elevation plate at the back of your dish. To set the correct elevation angle loosen the bolts that connects the elevation plate to the triangle base sufficient so that the reflector can move up or down without binding. Carefully set the elevation towards the angle value of your area. Look at other properties in your town. You may find that dish placement restrictions have been overcome by discreet placement. You now need a compass like the ones sold by outdoor stores - this one cost around 7. Rotate the numbered dial so that the azimuth value you found earlier is by the black marker.

Twenty eight degrees S. E. The satellite dish will often work behind a little obstacle or a larger obstacle farther away . The satellite signal comes down at around 50 degrees so for example if your dish is on chimney however the ridge tile is higher so long as you have 3 or 4 yards and the ridge tile is not more than a yard above it’ll probably work.


Fix the dish and rotor arm to the motor and adjust the elevation from the dish (declination) according to the motor manual Or simply adjust it so the face of the dish is about vertical or tilting up slightly (depending on your Latitude).

Make sure all of your connections are tight and weatherproof.

To prevent legal complications, satellite TV provider like Dish Network and DirecTV require the residents to get a landlord permission form filled and signed through the landlord before installation of the satellite TV system at the customers premises.

Level the mast attach the dish parts, connect the cables, and make final connections.

Be certain to get the dish right in the centre of the beam, by looking into making a note of where the signal drops off each side and take the centre reason for between. Some tools to consider before getting started: satellite signal finder, complete satellite system coax cable 7/16 wrench nut driver bit, zip ties or black tape staples or screw clips post level, lag bolts and small compass.

Then slowly tilt the dish up and down (elevation movement) to improve the signal quality strength reading that is measured in percentage (%). When you’re satisfied that you have the strongest signal using the signal quality bar (not the signal level bar) tighten the elevation bolts.

Do not puncture the cable when attaching towards the house. This can reduce signal or cause weather damage.

Motorised Satellite Dishes

A long time ago if an individual wished to begin receiving satellite TV development one thing they’d to perform was to go and buy a satellite TV method and choose how they were going to have it hooked up. Switch on your TV. Follow the instructions in your satellite dish manual to make sure your TV includes a signal. Once you have the best signal possible by adjusting the azimuth tighten on the bolts just enough to keep the dish from turning. Again turn your db level down on the meter (if required) and fine tune the elevation for the best possible signal. If you have a skew setting for the dish type, you don’t need to adjust it in this process. Now once the dish and motor have been bought the second step is how to mount the dish this depends on house type and location the dish must be mounted with out any obstacles in front of it so the higher the greater if your lucky and have a big garden to the south side of the house. Purchasing a complete kit is a good way of saving money and you know that everything you have purchased was designed to work together. Assemble the dish and DiSEqC motor. Taking care to set the Latitude/Elevation scale around the motor correctly. If you can obtain a clean arc as far as 45 degrees east and 45 degrees west there are a few more interesting satellites you are able to recieve. While attempting to align your dish, it is quite easy to think you have it pointed at the right satellite, but usually have it pointed at something else by mistake (often Astra1). Take this into account if you appear to be getting a strong signal but can not seem to tune anything in! Make sure that your view to the Southern sky’s unobstructed at the elevation angle you’ll be setting your dish at. When the setting for your area is 45 degrees, look into the sky at a 45 degree angle to ensure the sky is clear.

Run a good quality benchmarked coaxial cable from the dish to where your receiver is going to be and connect the two together ensuring you earn good f connections.

Satellite TV Of course not all satellite dishes will be used in homes/apartments. Some will be intended for use in an RV or tractor trailer. For many good diagramatic instructions on dish set up and installation you can visit the Winegard site to get a general idea of how the installation works. Running the cable. Run the RG6 cable with the dish and out the end to the LNBF (also known as the eye). Drill an opening big enough to accomodate your cable directly below your outlet boxes along with a hole either 1/2 inch or 3/4 through all of the joists in the planned route. Ladder remember, working at heights could be dangerous, and you are going to be drilling and carrying equipment down and up a few times if you dont feel confident then use a professional installer. You should check which satellites you are able to receive for your size / kind of dish on the satellite forums. You may want to tweak your setup just a little to get a good signal on all satellites. To view paid channels, you will need to insert a valid subscription card for that satellite television provider in to the card slot on the front or back of the receiver. You may also need to connect the satellite receiver to a landline telephone outlet.

How you can Install A Satellite Dish Your self

Satellite technologies have made leaps and bounds over the last decade introducing the world to a whole new era of television entertainment. But have you ever wondered just how a satellite dish works So did we.


Satellite TV Survey the dish installation site - Before you start the actual installation process, take a good look at the site. Your site should be free of obstructions blockages and other such things that can hamper your dishs reception. Observe your neighbors have set up their dishes as well as in which positions to choose the best site for the satellite dish. A good angle will result in a steady and strong signal for your channels. When the motor is assembled you need to set your latitude, on the side of the motor bracket is a scale, and on the motors is a small mark alaign the mark with your latitude and tighten them up. There are receivers out there that use software to emulate these cam’s however these types of boxes are often for enthusiasts only and are quite expensive i. e. Dreambox.

The easiest way to check your signal would be to take an old portable TV outside, hook the coax up to the dish and also the decoder and wave the dish around until you find the German channel ZDF. This is one of the strongest channels on Astra 1 so is easy to find. Then if so required move round for your chosen satellite location. You will probably get some very strange looks in the neighbours but who cares You are going to have lots of lovely free Television channels to look at by the end of the day. Your television would have to be set to the channel you selected in order for you to receive the programming. When the audio/video/SCART outputs are used, your television typically will have to be switched to the “video” input mode.


When you compare cable vs satellite service, youll notice that the big difference may be the equipment used to deliver the cable signal or DISH Network satellite signal to your household.

Be careful if you are installing on a chimney. I have heard cases of chimney collapse because of the wind loading around the dish causing failure of the mortar during storm conditions. Decide on a sensible route for the coax cable before you start tacking it into place. I discovered it easier to disconnect the cable in the dish, and start in the tv end from the cable although it doesnt really matter. Satellite cables come in 3 main colours that are white brown and black. You need to use the colour of cable that is most pleasing to the eye. I find black cable is most effective to brick houses. Send the dish to YOUR due south satellite OR the satellite closest to your longitude. This is almost invariably where the main power service enters the residence. A minimum of it will be there when it’s needed, avoiding the drilling of any unsightly holes within the future. Be secure: When installing a dish or antenna you will be going on your roof you need to be safe and cautious so you don’t risk falling. If the roof is wet then you shouldn’t go on it until it’s dry because it will be very slippery. You could also put the dish on the ground mount in an inconspicuous corner from the garden. Then plant some bushes, or erect fencing panels around it to screen it from view. So long as the dish includes a clear view south-east you’ll be ok.
